Heat Treatment PSA Nitrogen Generator Package System BV / CCS Certification
PSA Nitrogen Generator introduction
Nitrogen generation system uses pressure swing adsorption principles at normal temperatures, along with clean, compressed air as the raw material, and a carbon molecular sieve as the adsorbent, the adsorbent we use from Japan & German guarantee the working life over 20 years,
Due to oxygen and nitrogen different sieves, CMS under pressure adsorbing the oxygen pass through nitrogen, by pneumatic valve control PLC system to get required nitrogen purity .
PSA Nitrogen Generator Application:
Aircraft& motor vehicle tires
Chemical and petrochemical industries
Electronics industry
Metallurgy / heat treatment
Pharmaceutical industry
Glass and lighting industry
Oil & Gas
PSA Nitrogen Generator Benefits
· Experience - We have supplied over 1000 Nitrogen Generators all over the world.
· German Technology - We have German collaboration for our technology and have fine tuned this
technology to gain proprietary advantages in several key areas.
· Automated Operation - PSA Nitrogen Gas plants we manufacture incorporate complete automation
and no personnel are required for operating the Gas plant.
PSA Nitrogen Generator Specifications:
| No | Model | Capacity(Nm3/h) | Purity | Power(KW) | Overall size(mm) |
| 1 2 3 4 | PN-3-39 PN-5-29 PN-5-295 PN-8-295 | 3 5 5 8 | 99.9% 99.5% 99% 95% | 0.5 | 1800*1400*1500 |
| 5 6 7 8 | PN-5-49 PN-8-39 PN-12-295 PN-15-29 | 5 8 12 15 | 99.99% 99.9% 99.5% 99% | 0.5 | 1800*1400*1800 |
| 9 10 11 12 | PN-10-49 PN-15-39 PN-25-295 PN-30-39 | 10 15 25 30 | 99.99% 99.9% 99.5% 99% | 0.5 | 2000*1700*2250 |
| 13 14 15 16 | PN-15-49 PN-22-39 PN-35-295 PN-45-29 | 15 22 35 45 | 99.99% 99.9% 99.5% 99% | 0.5 | 2100*1800*2200 |
| 17 18 19 20 | PN-20-49 PN-30-39 PN-50-295 PN-60-29 | 20 30 50 60 | 99.99% 99.9% 99.5% 99% | 0.5 | 2200*1800*2200 |
| 21 22 23 24 | PN-30-49 PN-45-39 PN-75-295 PN-88-29 | 30 45 75 88 | 99.99% 99.9% 99.5% 99% | 0.5 | 2400*1900*2200 |
| 25 26 27 28 | PN-40-49 PN-60-39 PN-100-295 PN-120-29 | 40 60 100 120 | 99.99% 99.9% 99.5% 99% | 0.5 | 2500*2100*2500 |
| 29 30 31 32 | PN-50-49 PN-70-39 PN-120-295 PN-140-29 | 50 70 120 140 | 99.99% 99.9% 99.5% 99% | 0.5 | 2600*2200*2850 |
| 33 34 35 36 | PN-60-49 PN-90-39 PN-160-295 PN-190-29 | 60 90 160 190 | 99.99% 99.9% 99.5% 99% | 0.5 | 2800*2200*2500 |
| 37 | PN-80-49 | 80 | 99.99% | 0.5 | |
| 38 39 40 | PN-120-39 PN-200-295 PN-250-29 | 120 200 250 | 99.9% 99.5% 99% | 0.5 | 3200*1400*2800 |
| 41 42 43 44 | PN-100-49 PN-140-39 PN-250-295 PN-290-29 | 100 140 250 290 | 99.99% 99.9% 99.5% 99% | 0.5 | 3500*1500*2800 |
| ... | ... | ... | ... | ... | ... |
| Note:More news please free to contact Since Gas System Co.,Ltd or send email to us directly |
During the last 10 years,about 98% old customers firmly choose SINCE
Why they always choose SINCE?
Many years of experience and expertise in manufacturing and supplying gas plants;
,CCS,TS certified company for quality gas plants and best after -sale services; SINCE is the seldom company who got ,TS (Manufacture License of special equipment)
CCS(CHINA CLASSIFICATION SOCIETY) certificate,SINCE also can manufacture marine nitrogen generator.Excellent infrastructure set up teamed by experienced and qualified engineers.
Sophisticated and developed R&D wing in assistance for installation and use of plants.
